Packaging Box Making Machine Printer Slotter Rotary Die Cutter Auto
Stacker
Model:1200x2400
General descriptions of the whole machine
1. Roller type lead edge feeder for precise feeding, long life and
convenience.
2. Main transmission gear using high quality alloyed steel through
chamfered and grinding treatment for precise and stable work.
3. Bearings are of Famous brand: NSK or HAWALUO.
4. Key-free rings for high precise transmission to guarantee the
correct registration.
5. Motorized gap micro-adjustment, convenient and quick.
6. Spray oil lubrication: each gearbox keeps oil for continuous
spray lubrication.
7. Complete bearings grease lubrication system.
8. PLC control, auto sheet counting, speed indication, skip
feeding, trouble alarming, etc..
9. Main electrical parts are of Siemens or Schneider.
10. Main machine start protection: no lock, no run, for wrong
operation.
11. Motorized walk: motorized open and close, pneumatic lock.
Motorized walk with continuous alarming to safeguard the
maintenance
technicians. Auto braking device to ensure printing unit
non-movement.
12. Emergency stop: inside emergency stop on each unit to stop
machine walking during maintenance.
13. One-key order renewal start, effective encoder with 1mm
precision, no need order memory.
14. Independent operation counter
Technical Parameters
| Max.sheet size | 1250X2550mm |
| Design speed: | 250pcs/min. |
| Max. working speed: | 200pcs /min.(by sheet size and quality) |
| Max.working size: | 1200X2400 |
| Skip feeding size: | 1500mmX2400mm |
| Min.sheet size: | 320mmX600mm |
| Max.printing area: | 1200X2400mm |
| Cliché thickness: | 2-7mm |
| Max. paper thickness | 1-12mm |
| Slotting accuracy | ±1.5mm |
| Die cutting accuracy | ±1mm |
| Lead edge feeding error | ±1mm |
| Slotting width | 7mm |
| Max. slotting depth | 320mm |
| Corner cutting width | 50mm |
| Cliché cylinder diameter(including cliché) | 410mm |
| Cliché cylinder length | 2400mm |
| Machine inner width | 2900mm |
| Rubber roller thickness 25mm | Diameter 205mm |
| Anilox roller thickness 25mm | Diamter 215mm |
| Feeding up shaft thickness 20mm | Diamter 99mm |
| Feeding down shaft thickness 20mm | Diameter 156mm |
| Impression cylinder thickness 20mm | Diamter 156mm |
| Slitting Creasing shaft thickness 25mm | Diamter 110mm |
| Up die cutting cylinder thickness 35mm | Diameter 389mm |
| Down die cutting cylinder thickness 45mm | Diameter 360mm |
| Printing registration(medium speed): | ±0.3-0.5mm |
| Mesh mode: | 250,280 LPI |
| Dimension of the whole machine | 20000(L)x5000(W)x2300(H)mm |
| Total power(KW) | 104KW |
| Total weight(Ton) | 32 TONS |
| Wall thickness(mm) | 60mm(stabilize the high speed running) |
1. Lead Edge Feeding system
1. Vacuum transfer lead edge feeder.
2. Back buffle and side buffle are all motorized adjustment.
3. Feeder sliding block is of aluminum structure to guarantee a
more stable working with less vibration.
4. Sheet counting in touch screen.
5. Skip feeding for bigger sheet.
7. Pneumatic lift device with end chain-lock switch for convenient
operation.
1. Printing cylinder
1. Printing phase adjustment adopts satellite gear wheel structure,
PLC control, digital display, 360 degree circumferential
adjustment, stable start, correction positioning.
2. Grinded printing cylinder with harm chrome, with cross line and
center line, for convenient cliché fixation and sticking, correct
positioning and quick cliché registration.
3. Balance treatment, stable running, for high speed running.
4. Quick and convenient fixing system for the printing cliché.
5. Quick cliché change system to speed up the order renewal time.
6. Zero position device for printing cylinder for quick positioning
of cliché change and correction, for repeated carton specification
change. Foot stepping device for cliché fixation and dismantling.
Phase micro adjustment.
7. Printing cylinder left/right movement distance: 10mm.
8. Diameter of printing cylinder: ø524mm,ø304mm(with cliché
thickness)
