Corrugated Box Making Machinery Flexo Printer Slotter Rotary Die
Cutter
Model:1600x3000
Lead Edge Feeder
| Item | Descriptions |
1.Lead Edge Feeding system | 1.Vacuum transfer lead edge feeder. 2.Back buffle and side buffle are all motorized adjustment. 3.Feeder sliding block is of aluminum structure to guarantee a more
stable working with less vibration. 4.Sheet counting in touch screen. 5.Skip feeding for bigger sheet. 7.Pneumatic lift device with end chain-lock switch for convenient
operation. |
| 2.M/C open/cose | 1.Button auto control for machine open/close with alarm device to
safeguard operators. 2.Pneumatic locking system, whole machine locked on fixed track by
feeder main pneumatic cylinder. |
| 3.Feeding roll | 1. Endurable rubber-coated feeding roll to add use life. |
| 4. Zero return device | 1.Computer adopts zero return device with memory function to
guarantee the same adjustment standard, auto adjustment of correct
position to reduce the waste of boards. |
| 5. Servo control | Double Servo control-England CT |
| 6. Motorized baffle adj. | Left and right baffle motorized adjustment on track. |
| 7. Safety protection bar | To guard against unexpected injury on operation side. |
| 8. Supervision screen | To supervise the things happening nearby auto stacker. |
Die Cutter Unit
1.The rubber cushion roller can move at axial direction
automatically and circularly.
2. Covered with the best-in-class rubber, the cushion roller can
perform perfectly.
3. It is designed with auto-reconditioning device for worn cushion
roller.
4. The linear speed of the upper and lower rollers will be
automatically compensated after they are repaired.
5. The die cutter unit comes with versatility. That is, it is
favorable for quick change of slotting and die cutting.
How does an Auto Printer Slotter Die Cutter Stacker work?
The machine prints, slots, die-cuts, and stacks by following a
predetermined pattern. The operator first loads the sheets of
corrugated board into the feeding mechanism of the machine. The
feeding mechanism then moves the sheets to the printing unit, where
the design is printed onto the sheets in a single pass. After
printing, the sheets move to the slotting unit, where the machine
cuts slots into the sheets to create the desired dimensions of the
box or carton.
Next, the sheets are directed to the die-cutting unit, where the
machine uses a die to cut out the shapes and sizes of the packaging
products required. The die is customizable, and the machine can
change it to produce different products. After die-cutting, the
machine stacks the finished products into piles ready for the next
stage.
