1.Button auto control for machine open/close with alarm device to
safeguard operators.
2.Pneumatic locking system, whole machine locked on fixed track by
feeder main pneumatic cylinder.
3. Endurable rubber-coated feeding roll to add use life.
4. Computer adopts zero return device with memory function to
guarantee the same adjustment standard, auto adjustment of correct
position to reduce the waste of boards.
Features;
1.Seamless steel pipe for precise processing, balance treatment for
stable running, grinding and hard chromed.
2.Impression cylinder gap adopts adjustable offset ring, with close
structure, precise positioning, adjustment scope: 0-12mm
3.Up feeding roll: grinded and hard chromed.
4.Lower feeding roll: grinded, sand-frosted and hard-chromed.
5.Lower feeding shaft gap adjustment adopts offset ring with close
structure, correction positioning, adjustable at 0-12mm.
6. Seamless steel pipe for precise processing, balance treatment for
stable running, grinding and hard chromed
7 .Steel pipe rubber-coated durable for longlife.
8 .Super clutch and auto empty run device against ink dry.
9 .Midheight grinding for high LPI big space printing.
10 . Rubber roll open/close adopts worm gearbox manual adjustment,
with worm gearbox for gap adjustment with scale indication
11. Seamless steel pipe for precise processing, balance treatment
for stable running, grinding and hard chromed.
12.Longlife running, anti-grinding and erosion, ideal ink
transferring and controlling performance.
13.Pneumatic anilox auto elevation device and empty run device.
14.Speed difference between anilox roll and rubber roll for ink
doctoring effect to increase printing quality.
15.Single-way pneumatic membrane auto circulating pump.
16 . Ink filtering net to filter the dirt for nice printing result.
17 .Encased ink chamber.
18 .Satelite gear wheel design.
19 .Motorized circumferential adjustment, digital display, 360
degree run or stop adjustment.
20 .PLC control, quick reach, convenient for cliché adjustment.
21 . Manual gap Pressure adjustment for all units.
| Sheet size | 1600X3600mm |
| Design speed: | 160pcs/min. |
| Max. working speed: | 120pcs /min.(by sheet size and quality) |
| Max.working size: | 1600X3600 |
| Skip feeding size: | 1900mmX3400mm |
| Min.sheet size: | 350mmX600mm |
| Max.printing area: | 1600X3400mm |
| Cliché thickness: | 7mm |
| Slot width x Slot depth: | 7mmX400mm |
| Max. paper thickness | 10mm |
| Slotting accuracy | ±1.5mm |
| Printing registration(medium speed): | ±0.5mm |
| Mesh mode: | Optional(120-250LPI) |
| Dimension of the whole machine | 20200(L)x4600(W)x2800(H)mm |
| Total power(KW) | 60KW |
| Total weight(Ton) | 50TONS |
.....
