Corrugated Box Printing Machine High Speed Printing Slotter Die
Cutter
Model: 1800x4200
High degree of automation: automatic carton sticking machine has a
high degree of automation, without manual intervention, can
automatically complete the carton folding, bonding, coding and
other operations.
High production efficiency: automatic carton sticking machine can
quickly complete a large number of carton production tasks,
production efficiency is much higher than the traditional manual
production mode.
Good bonding quality: The carton with automatic carton bonding
machine is of good quality and not easy to crack or spread.
Simple operation: automatic carton sticking machine is simple to
operate, only need to enter the size and quantity of the carton,
the machine can automatically complete all the operations.
Small floor area: The volume of the automatic carton sticking
machine is relatively small, the floor area is not large, suitable
for a variety of different production sites.
Save labor cost: Because the automatic carton sticking machine can
automatically complete the carton production task, so it does not
need a lot of manpower input, can effectively save labor cost.
| Max.sheet size | 1800X4200mm |
| Design speed: | 60-100pcs/min. |
| Max. working speed: | 100pcs /min.(by sheet size and quality) |
| Max.working size: | 1800X4200 |
| Skip feeding size: | 2100mmX4200mm |
| Min.sheet size: | 380mmX700mm |
| Max.printing area: | 1600X4000mm |
| Cliché thickness: | 2-7mm |
| Max. paper thickness | 2-12mm |
| Slotting accuracy | ±1.5mm |
| Die cutting accuracy | ±1mm |
Features of Printer Unit
1. The flexo printer slotter is equipped with a steel anilox
roller.
2. The inking system employs a rubber cushion roller.
3. Due to a quick flexo plate changing device, the flexo plate can
be easily mounted and dismounted.
4. Phase adjustment in printing features PLC and touch screen
control which can achieve 360 degree adjustment.
5. Planetary gear type phase adjustment device shows long service
life.
6. The flexo printing machine is equipped with an automatic brake
which will prevent the print cylinder from rotating when it is
separated or in phase adjustment, thus keeping the original gear
position unchanged.
7. With auto reset system, the print cylinder can be automatically
returned to zero after being washed.
8. The printer is equipped with an auto anilox roller lifting
device which automatically lifts the anilox roller and makes it
separated with the printing plate when the feeding stops.
9. All clearance adjustments are completed by computer.
Customizable
The auto printer slotter die cutter stacker is customizable, which
means that printing companies can request a machine that meets
their specifications. They can specify the size and shape of the
packaging products they want to produce, and the machine will
produce them accurately.
