Brand Name : | HS |
Model Number : | 1600x3200 |
Certification : | CE |
Price : | USD |
Payment Terms : | T/T |
Supply Ability : | 20 units/month |
Delivery Time : | 100 -140days |
Corrugated Box Making Machine
Model:1600x3200
SUMMARY OF MACHINE
Fully Automatic Corrugated Box Making Machine a kind of Flexo
Printer Slotter Die cutter, or Flexo Folder Gluer Machine, which
used for making corrugated carton boxes from cardboard, with high
efficiency, Stable Running, Reliable and Durable.
TP-CR Series Flexo Printer Slotter Die Cutter is the 2nd step for
making Corrugated Cartons, it mainly used for Feeding, Printing,
Slotting or Die cutting, Stacking the cardboard, after this
machine, then used a automatic Gluing or Stitching machine, then we
can get a finished cartons.
This machine equipped with Lead Edge Feeder, Vacuum Transfer, Six
Shaft Rotation Slotter, or Eight Shaft rotation Slotter (Dual
Slotter Optional), Die Cutter, and Stacker. For High Graphic
Printing, there is a Chambered Doctor Blade System and Ceramic
Rollers as Optional.
Model | 1600x3200 |
Machine Speed(m/min) | 180 |
Machine Max.speed (pcs/min) | 150 |
Machine Max.feeder Size(mm) | 1600x3200 |
Machine min.feeder Size(mm) | 450x760 |
Machine Max. printer size (mm) | 1600x3100 |
thick of printer Plate(mm) | 7.2 |
Max. slotter Dep (mm) | 560 |
Max. Thickness of Sheet(mm) | 15 |
Machine size (LxWxH) | 21852x7370x2500 |
What is the difference between a carton box and a cardboard box?
Carton board is the name for a container that is made of paperboard and often corrugated fibreboard. It is known for its sturdy and rigid properties, making it a popular choice for packaging. It is often mistaken for cardboard, but actually cardboard is a heavy duty type of paper made in varying strengths/thicknesses
Lead Edge Feeder
1. Lead edge paper feeding system which can greatly reduce the jam during the paper feeding;
2. Lateral baffle is electrically adjusted and front and back baffle is manually adjusted;
3. Paper feeding counter can set and display production quantity;
4. Paper feeding wheel is made of polyurethane possessing strong friction force and long durability;
Scorer wheel gap, turbo box electric adjustable, graduated disc display adjust range -mm. Alloy tool steel with heat treatment, grinded slot teeth, good hardness and toughness. Scorer wheel, guide wheel, slot knife seat synchronous transverse displacement, PLC touch screen and electric button dual control. Planet gear structure, absolute value plate positioning, auto zero
.
![]() |
