General descriptions of the whole machine
●Roller type lead edge feeder for precise feeding, long life and
convenience.
●Main transmission gear using high quality alloyed steel through
chamfered and grinding treatment for precise and stable work.
●Bearings are of Famous brand: NSK, HRB.
●Key-free rings for high precise transmission to guarantee the
correct registration.
●Manual gap micro-adjustment, convenient and quick.
●Spray oil lubrication: each gearbox keeps oil for continuous spray
lubrication.
Electrical auto control system:
●PLC control, auto sheet counting, speed indication, skip feeding,
trouble alarming, etc..
●Main electrical parts are of Schneider or Omron or Siemens.
●Main machine start protection: no lock, no run, for wrong
operation.
●Motorized walk: motorized open and close, pneumatic lock.
Motorized walk with continuous alarming to safeguard the ●maintenance technicians. Auto braking device to ensure printing
unit non-movement.
Emergency stop: inside emergency stop on each unit to stop machine
walking during maintenance.
| Max. sheet size | 600X1850mm |
| Design speed: | 500pcs/min. |
| Max. working speed: | 200-300pcs /min.(by sheet size and quality) |
| Max. working size: | 600X1800mm |
| Skip feeding size: | 800mmX1850mm |
| Min. sheet size: | 170mmX420mm |
| Max. box height: | 150mm |
| Min. box height: | 70mm |
| Min. slotting Counter-blade: | 150x50mm square blade: 85x85mm |
| Max.printing area: | 600X1800mm |
| Cliché thickness: | 7mm |
| Slot width x Slot depth: | 7mmX400mm |
| Max. paper thickness | 10mm |
| Slotting accuracy | ±1.5mm |
| Printing registration(medium speed): | ±0.5mm |
| Mesh mode: | Optional(180,200,250, 250 LPI) |
| Dimension of the machine | 24000(L)x3300(W)x2200(H)mm |
| Total power(KW) | 48KW |
| Total weight(Ton) | 32TONS |
