    Carton Box Printing Slotting Machine with Die Cutting

    Ask Lasest Price
    Brand Name : HS
    Model Number : 1600x3200
    Certification : CE
    Price : USD
    Payment Terms : T/T
    Supply Ability : 20 units/month
    Delivery Time : 100 -140days
    • Product Details
    • Company Profile

    Carton Box Printing Slotting Machine with Die Cutting

    High Speed Printer Slotter And Die Cutter




    Model1600x3200
    Machine Speed(m/min)180
    Machine Max.speed (pcs/min)150
    Machine Max.feeder Size(mm)1600x3200
    Machine min.feeder Size(mm)450x760
    Machine Max. printer size (mm)1600x3100
    thick of printer Plate(mm)7.2
    Max. slotter Dep (mm)560
    Max. Thickness of Sheet(mm)15

    Machine size (LxWxH)


    21852x7370x2500

    Rotary Die-Cutter Unit Features:

    A. Die Cylinder (Lower)

    Ground and chromed high quality steel

    Dynamic balanced for stable running.

    Fixing hole distance is 50mm lateral.

    Creasing height is 22.60mm.

    Wooden die thickness is 13mm.

    B. Anvil Cylinder (Upper)

    Ground and chromed high quality steel

    Dynamic balanced for stable running.

    Anvil cover thickness is 10mm,width is 252mm.

    Side to side oscillation of anvil cylinder( 50mm).

    Motorized gap adjustment between anvil roll and die cylinder.

    C. Self-locking System Adopted for Pulling Roll Gap.

    D. Cam bearing applied for the Pull Roll working, wear reduced and run more stable.

    E. Cutting Registration Adjust System

    Planetary gear system

    Cutting registration controlled by PLC and motorized, 360°adjust.

    Lateral registration controlled by PLC and motorized, range ±10mm.

    F. Anvil Speed Compensating System with Dependent Motor, range ±3mm.

    G. With Anvil Grinding System for Keeping Smooth.


    Safety instructions


    Before operating this machine, please read the following safety guidance for complete understanding:

    • Please operate this machine according to the manufacturer’s guidance and your factory relative safety operation regulations.
    • A clean and neat working area should be sustained.
    • All the safety protection devices should be placed properly in position and all the safety operation switches should be running normally.
    • Operators should wear suitable uniforms and use all necessary safety devices (for example, to wear gloves when operating and inspecting the machines)
    • Fasten the loose hair and clothes to avoid contact with movable equipment.
    • Find out the damaged or worn parts of the machine and arrange the experienced technicians to repair or adjust the machine.
    • Remember never touch the moving equipment manually or with tools.
    • Lock the power source and be sure the keys are at your hand when making maintenances.
    • Remind the non-duty persons to keep away far from the working area when switching off or starting the machine.




    .
