Brand Name : | box manufacturing machine |
Model Number : | Jumbo size 2200x5200 |
Standard equipment:
A. Pressure-free double servo Lead Edge Feeder;
B. Two color printers with metallic anilox rollers;
C. Motorized Single Slotter(6 shafts)
D. Rotary Die Cutter (independent servo driving);
E. Vibration Stripper;
F. Auto Stacker;
Tech parameters: 380V, 50HZ, 3 phase, 4 wire (end user will prepare transformer)
Max.sheet size | 2200X5200mm |
Design speed: | 100pcs/min. |
Max. working speed: | 80pcs /min.(by sheet size and quality) |
Max.working size: | 2150X5300 |
Skip feeding size: | 2500mmX5200mm |
Min.sheet size: | 550 mmX700mm |
Max.printing area: | 2100X5200mm |
Cliché thickness: | 7.2mm |
Max. paper thickness | 1-15mm |
Slotting accuracy | ±1mm |
Die cutting accuracy | ±1mm |
Lead edge feeding error | ±1mm |
Slotting width | 7mm |
Max. slotting depth | 480mm |
Corner cutting width | 50mm |
Cliché cylinder diameter(including cliché) | 700mm |
Cliché cylinder length | 5200mm |
Machine inner width | 5600mm |
Rubber roller thickness 30 mm | Diameter 280mm |
Anilox roller thickness 30mm | Diamter 275mm |
Feeding up shaft thickness 20mm | Diamter 99mm |
Feeding down shaft thickness 25mm | Diameter 176mm |
Impression cylinder thickness 25mm | Diamter 270 mm |
Slitting Creasing shaft thickness 25mm | Diamter 155mm |
Up die cutting cylinder thickness 35mm | Diameter 643.9mm |
Down die cutting cylinder thickness 45mm | Diameter 650mm |
Printing registration(medium speed): | ±0.5mm |
Mesh mode: | 220,250 LPI |
Dimension of the whole machine | 17500(L)x6000(W)x2300(H)mm |
Total power (KW) | 130KW |
Total weight(Ton) | 64 TONS |
Wall thickness(mm) | 60 mm |
The corrugated board printing machine is an essential tool for
those in the printing industry. It is used to create high-quality
and durable corrugated boards that are used in various
applications, including packaging, shipping, and storage. The
carton box packing machine 1600x2800 model is equipped with a steam
heating system that ensures the corrugated boards produced are of
the highest quality and can withstand harsh conditions.
The corrugated box packaging machine is suitable for use in various
occasions and scenarios. It is ideal for use in the food and
beverage industry, where it is used to package food products such
as fruits, vegetables, and grains. It is also suitable for use in
the electronics industry, where it is used to package delicate
electronic components and devices.
The carton box packing machine 1600x2800 model is a durable and
reliable machine that comes with a one-year warranty for the whole
machine. It has a total power of 50KW, making it an efficient and
cost-effective option for those in the packaging industry. Whether
you are a small business owner or a large corporation, this machine
is an essential tool for your packaging needs.
The Corrugated Carton Machine is a highly advanced piece of
equipment designed to streamline the process of creating corrugated
cartons. Our product technical support team is dedicated to
ensuring that our clients receive top-notch assistance with their
machine. We offer comprehensive technical support services,
including troubleshooting, maintenance, and repair assistance. Our
team is highly skilled and knowledgeable about our product and can
assist customers with any questions or concerns they may have.
In addition to technical support, we also offer a range of services
designed to help our clients get the most out of their corrugated
carton machine. Our services include installation and setup
assistance, operator training, and product customization. We
understand that each of our clients has unique needs, and we are
committed to providing personalized service to meet those needs.
At Corrugated Carton Machine, we are committed to providing the
highest level of product technical support and services to our
clients. Contact us to learn more about how we can assist you with
your corrugated carton machine needs.
Product Packaging:
The Corrugated Carton Machine will be packaged in a sturdy
cardboard box with foam padding to ensure safe transport. The box
will be labeled with the product name and weight for easy
identification.
Shipping:
We offer worldwide shipping for the Corrugated Carton Machine.
Shipping costs will vary depending on the destination and shipping
method selected at checkout. We strive to process and ship all
orders within 1-2 business days of receiving payment. Once shipped,
you will receive a tracking number to track your package.
Q: What is the brand name of the corrugated carton machine?
A: The brand name of the corrugated carton machine is carton box
packing machine.
Q: What is the model number of the carton machine?
A: The model number of the carton machine is 1600x2800.
Q: Where is the carton machine made?
A: The carton machine is made in China.
Q: What is the capacity of the carton machine?
A: The capacity of the carton machine varies depending on the size
and complexity of the carton being produced. However, it is capable
of producing a large volume of cartons per hour.
Q: Can the carton machine be customized?
A: Yes, the carton machine can be customized according to the
specific needs and requirements of the customer.
![]() |
