Capacity Resolution Paper/Plastic Inkjet Printing Machine

Ask Lasest Price
Brand Name :	HS
Model Number :	1426

Add to Cart

Product Details
Company Profile

Capacity Resolution Paper/Plastic Inkjet Printing Machine

Model	920	1224	1228	1426
Max. Speed(pcs/min)	300	250	230	200
Max Feeding Size(mm)	900×2000	1200×2400	1200×2800	1400×2600
Min Feeding Size(mm)	260×600	320×600	320×600	420×600
Skip Feeding (mm)	1200×2000	1500×2400	1500×2800	1700×2600
Max. Printing Area(mm)	900×1960	1200×2360	1200×2760	1400×2560
Min. Slotting Reverse knife(mm)	240×65×240×65	260×65×260×65	260×65×260×65	260×65×260×65
Min. Slotting Normal knife(mm)	130×130×130×130	130×130×130×130	130×130×130×130	130×130×130×130
Slotting Depth (mm)	250	300	300	350

  FEEDING UNIT    The Central Console is adopted to Windows system for easily
operating.Feeding gaps adjustment are computerized control with
screen display    Auto zero-set for feeding position to reduce
adjusting time.    Servo Control Non-crush Feeding System as
optional.    Feeding volume is frequency control and can be
adjusted according to cardboard size.    Main motor,suction blower
and dust suction are frequency control.    The speed can be adjust
freely with synchronous belt drive.    For example as 1426 model
Lead Edge Feeder equipped with 4 axis for transmission.    The
extension dust removing system with 4 blower fans, 2 brushes, and
anti-static system optional.    The permanent magnet fan frequency
conversion controls the vacuum air flow and pressure, which can
adapt to different cardboard specifications, save energy and reduce
noise

  DIE CUTTING UNIT    Independent Frequency Motor for Line Speed Compensation
Servo independent drive is optional    Die-cutting Register servo
control.    Line speed compensation frequency control.    With
automatic grinding device    Auto zero- set for die cutting
position.
